Place of Origin :
Shanghai, China
Price :
Negotiable
Harmonic Filtering Range :
2nd - 50th harmonic, independently selectable
Overload Capacity :
110% rated current, 1 minute
Display Interface :
Intelligent LCD touch screen HMI
Delivery Time :
7-15 days, subject to order quantity
Model Number :
HPFC-600
Enclosure Protection Degree :
Floor-standing cabinet with modular AHF power modules, IP54
Dynamic Response Time :
<= 100 us detection; full compensation within 10 ms
Brand Name :
Nengdu
Supply Ability :
100 Sets per Month
Product Type :
Active Harmonic Filter AHF (active power filter)
Protection Functions :
Over-voltage, under-voltage, over-current, over-temperature, short-circuit and phase-loss protection
Warranty :
36 months with 100% inspection before shipment
Rated Current :
100 A
Compensation Modes :
Harmonic filtering; optional reactive power compensation and three-phase load balancing
Communication :
RS485 (Modbus-RTU), dry contacts; Ethernet optional
Payment Terms :
T/T,L/C,Western Union
System Frequency :
50/60 Hz (auto-adaptive)
Cooling Method :
Intelligent forced-air cooling with temperature-controlled fans
Residual THDi :
< 5% (typically < 3% at full load)
Filtering Efficiency :
> 97%
Packaging Details :
Export wooden case
Installation :
Parallel connection to the power grid; modular parallel expansion supported
Certification :
CE,IEC,RoHS,ISO9001
Rated Voltage :
400V AC (three-phase)
Weight :
Approx. 380 kg
Noise Level :
<=60 dB(A)
Wiring Mode :
Three-phase four-wire (3P4W)
Dimensions W x D x H :
800 x 800 x 2000 mm
MOQ :
1 Set
Altitude :
<= 2000 m (derating above 2000 m)
Standards Certification :
ISO 9001:2015, CE, IEC 61000 series
